8N1498 powertransformer for tube amplifier (329VA)
Specifications :
- Power rating : 329VA
- Primary winding : 2x115V / 230V
- Secondary winding :
380V - 0 - 380V @ 300mA
0 - 5V - 6.3V @ 6A
0 - 5V - 6.3V @ 3A
0 - 5V - 6.3V @ 3A
0 - 6.3V @ 2A
0 - 6.3V @ 2A
- Diameter : 121mm
- Height : 56mm
- Mounting materials supplied
Downloads:
KEMA KEUR Approval
This transformer is wound , tested and approved according to the European standard EN61558.
The products aswell as the production location are inspected regularly by a certified body.
"KEMA KEUR" is recognised in whole of Europe and offers unrestricted access to a lot of markets worldwide.
ENEC Approval
The quality approval ENEC for electrical apparatus and electronic products indicates
that this product meets the European Safety Standards and has been tested and approved
by a "Certified Body"UL/CSA Approval
Tested and approved by Underwriters Laboratories. This approval is used for the American and Canadian market.
This product has been tested and appoved by UL and carries the UL and/or CSA approval.
