2x 22V toroidal transformer 300VA
Specifications :
- Typenumber : 78015 / 77015
- Power rating : 300VA
- Primary winding : 230V(78015) of 2x115V(77015)
- Secondary windings : 2x 22V - 6.82A
- Secondary windings in series gives : 44V - 6.82A
- Secondary windings in parallel gives : 22V - 13.6A
- Diameter : 121mm
- Height : 56mm
- Mounting materials are included in the shipment
Downloads:
Download datasheet 78015 (PDF)
Download datasheet 77015 (PDF)
